GOLUB 9200VTC | Barebone [4x M12 w/PoE+, 1x PCIe]

Rugged PC for in-vehicle applications with PCIe • 13th Gen. Intel® Core™ i9/i7/i5/i3/Celeron

GOLUB 9200VTC is APROtechs latest rugged in-vehicle controller based on Intel® 14th/ 13th/ 12th-Gen Core™ processors. Benefiting from cutting-edge Intel® 7 photolithography, the latest Core™ desktop processors come with up to 24 cores/ 32 threads, offering an incredible boost of computational performance. Combining DDR5 memory bandwidth throughput and PCIe Gen4 NVMe high-speed disk read/write, users can expect an overall system performance improvement of up to 1.8x when compared to previous 10th or 11th-Gen platforms.

GOLUB 9200VTC offers an assortment of peripherals, connections, and expansion flexibility. It has 2.5Gb and 1Gb Ethernet ports, and four or eight 802.3at PoE+ ports to supply 25W of power to connected devices such as IP cameras. The system also has x-coded M12 connectors and screw-lock mechanisms on I/Os like Ethernet, USB 3.2 Gen1 and USB 3.2 Gen2 to guarantee extreme rugged connectivity in shock/ vibration environments. Internal expansion wise, there are two M.2 and three mini-PCIe sockets to install 5G/ 4G, WiFi, GPS, and CAN module for wireless communication.

On top of all that, the system is E-Mark/ EN 45545 certified and EN 50155 EMC compliant and has a patented Cassette module with an additional PCIe slot for an add-on card, making it that much more flexible for in-vehicle applications. GOLUB 9200VTC also features two hot-swappable SATA HDD trays, an isolated CAN bus for in-vehicle communication, isolated DIO for sensor/ actuator control, 8V to 48V wide-range DC input with ignition power control. The GOLUB 9200VTC series is a flexible and reliable solution for various in-vehicle applications.

Key facts	• 13th Gen. Intel® Core™ i9/i7/i5/i3/Celeron • Up to 64GB DDR5 • 1x PCIe slot • Up to 8x 802.3at PoE+ ports • E-Mark certified and EN 50155 EMC compliant
Protection class	IP20
CPU	Supporting Intel® 13th/12th-Gen Core™ CPU (LGA1700 socket, 65W/ 35W TDP)
Chipset	Intel® Q670E platform controller hub
RAM	Up to 64GB DDR5 4800 SDRAM (two SODIMM slots)
Storage interface	2x hot-swappable HDD trays for 2.5” HDD/ SSD installation, supporting RAID 0/ 1 • 1x M.2 2280 M key socket (PCIe Gen4 x4) for NVMe SSD
RAID	0/ 1
Ports	1x 2.5G Ethernet by I226-IT and 1x Gigabit Ethernet by I219-LM with screw-lock • 4x IEEE 802.3at Gigabit PoE+ ports by Intel® I210; - M12 X-coded connector (GOLUB 9200VTC); - RJ45 connector (GOLUB 9204VTC) • 4x IEEE 802.3at Gigabit PoE+ ports by Intel® I210 and 4x 2.5G PoE+ ports by I226-IT; - RJ45 connector (GOLUB 9208VTC) • 1x USB 3.2 Gen2x2 (20Gbps) port in type-C connector with screw-lock • 4x USB 3.2 Gen2x1 (10 Gbps) ports in type-A connectors • 2x USB 3.2 Gen1x1 (5 Gbps) ports in type-A connectors • 2x USB 2.0 ports • 1x isolated CAN 2.0 port • 1x VGA, supporting 1920 x 1200 resolution • 1x DVI-D, supporting 1920 x 1200 resolution • 1x DisplayPort, supporting 4096 x 2304 resolution • 2x software-programmable RS-232/ 422/ 485 ports (COM1/COM2) • 2x RS-232 ports (COM3/COM4) • 1x 3.5 mm jack for mic-in and speaker-out
PCI / PCIe / mini-PCIe	1x PCIe x16 slot@Gen3, 16-lanes PCIe signals in Cassette • 1x full-size mini-PCIe socket • 2x full-size mini-PCIe sockets (USB signals only) with internal SIM sockets • 1x M.2 2242/3052 B key socket with SIM slot for M.2 5G/ 4G module • 1x M.2 2242/3052 B key socket with SIM slot for M.2 4G module
DIO	4-CH isolated DI and 4-CH isolated DO
Cooling System	Passive, fanless
Mounting	Wall-mount with damping bracket
Power input	1x 3-pin pluggable terminal block for 8V to 48V DC input (IGN/ GND/ V+) • 1x 3-pin pluggable terminal block for remote control and PWR LED output • Built-in ignition power control
Power consumption	TBA
Operating system	Option: Microsoft Windows® 10 • Fedora 29 • Ubuntu 16.04.5 LTS & Ubuntu 18.04.0 LTS
Operating temperature	with 35W CPU -40°C to 70°C (with 1 memory module installed) • -40°C to 60°C (with 2 memory modules installed) with 65W CPU -40°C to 50°C (configured as 65W TDP with 2-slots memory)
Storage temperature	-40° to 85°C
Storage humidity	10% to 90%; non-condensing
Vibration	EN 50155:2017/ IEC 61373, Category I, Class B - Body mounted
Shock	EN 50155:2017/ IEC 61373, Category I, Class B - Body mounted
Certificate	E-Mark, EN 50121 (EN 50155 EMC) • CE/FCC Class A, according to EN 55032 & EN 55035
Weight / kg	3.9
Dimensions / mm	240 x 225 x 103
Scope of delivery	Accessory Kit • DVI to VGA Adapter • Wall Mount Kit • Utility DVD Driver
