HAWK AP 10-HEL | Intel® Celeron® J6412 [PCT]

10.1" (Widescreen) IP66 Human-Machine-Interface (HMI) with TPM

Key facts	• 10.1" ~ 21.5" • Intel® Celeron® J6412 • Max. 32GB DDR4 • IP66 • Fanless
Display Size	10.1" • 15.6" • 21.5"
Aspect ratio / resolution	16:10 / 1280 x 800 (10.1") • 16:9 / 1920 x 1080 (15.6"; 21.5")
Touch	Capacitive (PCT)
Protection class	IP66 Compliant Front Bezel
Front	Aluminium
CPU	Intel® Celeron® J6412, 4x 2.0GHz/2.6GHz, 1.5MB L2 cache
Chipset	Intel® Baytrail SoC - Embedded Long Life Chipset
RAM	1x 260-pin SO-DIMM up to 32GB DDR4 3200MHz
Storage interface	1x M.2 B-Key slot (support SATA3)
Ports	2x 2.5 Gigabit-LAN RJ-45 • 2x USB 3.2 Gen2 type A • 2x USB 2.0 type A • 1x RS-232/422/485 (default RS-232; select via BIOS) • 1x Line-out • 1x DP, support DP++
PCI / PCIe / mini-PCIe	1x M.2 E-key • 1x M.2 B-key • 1x Nano SIM slot
Cooling System	Passive, fanless
Mounting	Panel mounting • VESA 100 x 100
Power input	9V to 36V DC • 1x 3-pin Terminal Block Connector • 1x 2-pin Power Switch Connector
Power consumption	35W (10.1") • 40W (15.6") • 50W (21.5")
Operating system	Windows 10 IoT • Windows 11 IoT
Max. color	16.7M
Luminance /cd/m2	350 (10.1") • 400/500 (15.6") • 250 (21.5")
View angle / H/V	170°/170° (10.1") • 170°/160° / 178°/178° (15.6") • 178°/178° (21.5")
Backlight lifetime / hrs	30,000 (10.1") • 50,000 (15.6"; 21.5")
Contrast ratio	800:1 (10.1") • 500:1 / 1000:1 (15.6") • 1000:1 (21.5")
Operating temperature	0° to 50°C
Storage temperature	-30° to 70°C
Storage humidity	10% to 95% @ 40°C, non-condensing
Certificate	CE/FCC Class B
Weight / kg	2.4 (10.1") • 3.7 (15.6") • 6.5 (21.5")
Dimensions / mm	269 x 189 x 51 (10.1") • 405 x 256 x 59 (15.6") • 541 x 333 x 59 (21.5")
Scope of delivery	Power supply, 60W • 3-pin terminal connector • retaining clip • touch pen • driver CD
